Manufacturer
RFS
MPN
716M-LCF12-D01
MOQ
16
Available
16
Condition
New
GTE 716M-LCF12-D01 7-16 DIN MALE
The RFS 716M-LCF12-D01 is a high-quality 7-16 DIN male connector designed for use in telecommunications and wireless communication systems. This connector is specifically designed for use with LCF12 1/2" foam coaxial cables, making it a perfect fit for a wide range of applications.
It features a precision-machined brass body and silver-plated contacts for excellent conductivity and corrosion resistance. The 716M-LCF12-D01 is easy to install and provides a secure and stable connection, ensuring optimal signal transmission.
Ultra high PIM performance i.e. reduced interference leading to high customer satisfaction
Two-piece design i.e. visual inspection of interlocking leads to improved installation security
OMNI FIT concept i.e. streamlined order management and reduced stock level
Watertight sealing in mated and unmated condition, i.e. reduced efforts during installation and improved security during operation
Unique NiTin plating i.e. extreme resistance against corrosion even under hardest climatic and environmental circumstances
Multi-thread (Tristart) design i.e. simplified and accelerated tightening process
General Specifications | ||
|---|---|---|
| Transmission Line Type | Coaxial Cable | |
| Cable Size | 1/2 | |
| Cable Type | Foam Dielectric | |
| Model Series | LCF12-50 Series, ICA12-50 Series, RCF12-50 Series | |
| Connector Interface | 7-16 DIN | |
| Connector Type | OMNI FIT PREMIUM Straight | |
| Sealing Method | Polymer claw + 360° Compression | |
| Gender | Male | |
Electrical Specifications | ||
| Nominal Impedance, ohms | Ohm | 50 |
| 3rd Order IM Product @ 2x20 Watts | dBc | -163 ; typical -167 |
| Maximum Frequency | GHz | 3.7 |
| VSWR, Return Loss | VSWR (dB) | 0 < f ≤ 1.0 GHz: 1.02 (40) 1.0 < f ≤ 2.7 GHz: 1.03 (36.6) 2.7 < f ≤ 3.7 GHz: 1.06 (30.7) |
Mechanical Specifications | ||
| Plating Outer/Inner | NiTin/Silver | |
| Length | mm (in) | 55.8 (2.2) |
| Outer Diameter | mm (in) | 32 (1.26) |
| Inner Contact Attachment | Basket | |
| Outer Contact Attachment | 360° clamping | |
Accessories | ||
| Wrench size front | mm (in) | 26 |
| Wrench size rear | mm (in) | 26 |
| Trimming Tool | TRIM-SET-L12-D01 TRIM-LCF12-D01-A | |
Please refer to the following attachments for additional details on the product.
No specifications available.
