Manufacturer
Cisco
MPN
WS-G5484
MOQ
2
Available
365
Condition
New
Cisco WS-G5484 - Cpe Other 1000base-sx Short Wavelength Gbic (mu
The Cisco WS-G5484 is a high-quality, reliable GBIC (Gigabit Interface Converter) module designed for use in various networking applications. With a 1000base-sx short wavelength interface, this GBIC module is capable of transmitting data at high speeds over short distances, making it ideal for use in local area networks (LANs) and other short-range connections.
It is also compatible with a wide range of Cisco devices, ensuring seamless integration into your existing network infrastructure. This ensures that the module is built to the highest standards of quality and reliability, providing you with a dependable solution for your networking needs. With its compact design and easy installation process, this module is a cost-effective and efficient solution for all your networking requirements.
Key Technical Data | |
|---|---|
| Media Type: | Multi-Mode Fiber (MMF) |
| TX Wavelength: | 850 nm. |
| RX Wavelength: | 850 nm. |
| Minimum Optical Budget: | 7.5 dB |
| Maximum Distance: | 550m |
| Supported Data Rate: | 1.063-1.25Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double SC |
| Tx Wavelength Bandwidth: | 20 nm (840-860 nm) |
| Rx Wavelength Bandwidth: | 20 nm (840-860 nm) |
| Minimum Transmitting Power: | -9.5 dB |
| Maximum Transmitting Power: | 3 dB |
| Receiver Sensitivity: | -17 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 110 ps/nm |
| Transmitter Type: | VSCEL Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | SEMTECH, UX |
| Transceiver Type: | GBIC |
Please refer to the following attachments for additional details on the product.
No specifications available.
