Manufacturer
Cisco
MPN
SFP-OC12-SR
MOQ
2
Available
300
Condition
New
Cisco SFP-OC12-SR - Pdt Adapter 10-1970-01
The Cisco SFP-OC12-SR is a high-quality, reliable and efficient PDT adapter designed for use with Cisco networking equipment. This SFP-OC12-SR adapter is designed to provide a high-speed, high-bandwidth connection for data transmission over short distances. It supports a data transfer rate of up to 622 Mbps and can transmit data over a distance of up to 2 kilometers.
This makes it ideal for use in data centers, enterprise networks, and other high-speed networking environments. Simply plug it into the SFP slot on your Cisco device and it will be ready to use. It also features hot-swappable capabilities, allowing you to replace or upgrade the adapter without disrupting network operations.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 13 dB |
| Maximum Distance: | 20km |
| Supported Data Rate: | 1.063-1.25Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -9 dB |
| Maximum Transmitting Power: | -3 dB |
| Receiver Sensitivity: | -22 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 140-160 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
Please refer to the following attachments for additional details on the product.
No specifications available.
