Manufacturer
Cisco
MPN
SFP-OC48-SR
MOQ
3
Available
318
Condition
New
Cisco SFP-OC48-SR - Pdt Adapter Ip 12000 Line Connector
The Cisco SFP-OC48-SR is a high-performance pluggable transceiver module designed for use with the Cisco IP 12000 line of routers. This adapter is specifically designed for OC-48/STM-16 optical interfaces and provides a reliable and cost-effective solution for high-speed data transmission.
With a maximum data transfer rate of 2.5 Gbps, this SFP module is ideal for high-bandwidth applications such as data centers, enterprise networks, and service provider networks. It also features digital diagnostic monitoring capabilities, allowing for real-time monitoring of key parameters such as temperature, voltage, and optical power levels.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 8.5 dB |
| Maximum Distance: | 2km |
| Supported Data Rate: | 100-2.67Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 100M Ethernet (100Mbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), STM-1 (155Mbps), STM-4 (622Mbps), STM-16 (2.488 Gbps), ODU0 (1.244Gbps), ODU1 (2.498Gbps), OTU1 (2.66Gbps), CPRI option 1 (614.4 Mbps), CPRI option 2 (1228.8 Mbps), CPRI option 3 (2.458 Gbps), OBSAI RP3 x 1 (768 Mbps), OBSAI RP3 x 2 (1.536 Gbps) |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -9.5 dB |
| Maximum Transmitting Power: | 3 dB |
| Receiver Sensitivity: | -18 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 100-110 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
