Manufacturer
Ericsson
MPN
RDH10247/2
MOQ
5
Available
408
Condition
New
Ericsson RDH10247/2 - Sm Cpri 8km Gbe 1310nm Lc-sfp Rcpt
The Ericsson RDH10247/2 is a high-performance small form-factor pluggable (SFP) transceiver designed for use in telecommunications and networking applications. This transceiver is specifically designed for use with CPRI (Common Public Radio Interface) technology and is capable of transmitting data over distances of up to 8km.
The transceiver operates on the Gigabit Ethernet (GbE) standard and uses a 1310nm laser to transmit data. It is equipped with an LC-type connector, making it easy to install and connect to compatible devices. It is ideal for use in a variety of applications, including data centers, enterprise networks, and telecommunications networks.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 12 dB |
| Maximum Distance: | 10km |
| Supported Data Rate: | 1.063-1.25Gbps |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -9 dB |
| Maximum Transmitting Power: | 3 dB |
| Receiver Sensitivity: | -22 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 70-100 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
Please refer to the following attachments for additional details on the product.
