52-units min. Southwire 12 Awg List 2 Telcoflex Black Lszh 600v - 59532301
Slide 1 of 1
Manufacturer
Southwire
MPN
59532301
MOQ
52
Available
6,962
Condition
New
12 Awg List 2 Telcoflex Black Lszh 600v
The Southwire 59532301 is a high-quality 12 AWG List 2 Telcoflex cable designed for telecommunications applications. It features a black LSZH (Low Smoke Zero Halogen) jacket that is flame retardant and low in toxicity, making it safe for use in confined spaces.
This cable is rated for 600 volts and is suitable for both indoor and outdoor use. The 12 AWG copper conductors are twisted together for optimal signal transmission and are insulated with a durable LSZH material.
This cable is also resistant to UV rays, moisture, and chemicals, ensuring long-lasting performance in various environments. The Southwire 59532301 is UL listed and meets the requirements of the National Electrical Code (NEC) for Class 2 and Class 3 circuits.
It is also RoHS compliant, meaning it is free from hazardous substances. This Telcoflex cable is ideal for use in telephone systems, intercoms, and other communication applications. It is also suitable for use in data centers, control systems, and other low-voltage power applications.
Specifications | |
| Size (AWG or kcmil) | 12 AWG |
| No. of Strands | 65 |
| Nominal Total Weight (lbs/1000') | 36 |
| Allowable Ampacity at 75C | 25 |
| Allowable Ampacity at 90C | 30 |
| Insulation Thickness (mils) | 45 |
| DC Resistance at 25°C | 1.72 |
| Armor | NO |
| Composite | NO |
| Conductor Count | 1 CONDUCTOR |
| Conductor Material | TINNED OR COATED COPPER |
| Earth/Ground Wires | NO |
| Screen/Shield | UNSHIELDED |
| Conductor Type | STRANDED |
| Jacket Material | UNJACKETED/NON-SHEATHED |
| Voltage Range | 600V |
| Temperature Rating (Max) | 105°C |
| Cable Diameter Max (in) | 0.182 |
Please refer to the following attachments for additional details on the product.
No specifications available.
