59-units min. Micron MT41J256M16RE-125:D DRAM Chip DDR3 SDRAM 4Gbit - MT41J256M16RE-125
Slide 1 of 1
Manufacturer
Micron
MPN
MT41J256M16RE-125
MOQ
59
Available
0
Condition
Used
Micron MT41J256M16RE-125:D DRAM Chip DDR3 SDRAM 4Gbit
The Micron MT41J256M16RE-125:D is a high-performance DRAM chip designed for use in various electronic devices. It features DDR3 SDRAM technology and is ideal for applications that require fast and efficient data processing.
Application:
- General-purpose computing
- Server and data center applications
- Gaming systems
- High-performance computing platforms
Specifications | |
| Organization | 256Mx16 |
| Number of Words per Bank | 32M |
| Data Bus Width (bit) | 16 |
| Maximum Access Time (ns) | 0.225 |
| Process Technology | CMOS |
| Typical Operating Supply Voltage (V) | 1.5 |
| Operating Current (mA) | 280 |
| Maximum Operating Temperature (°C) | 95 |
| Number of I/O Lines (bit) | 16 |
| PCB changed | 96 |
| Lead Shape | Ball |
| Chip Density (bit) | 4G |
| Number of Internal Banks | 8 |
| Number of Bits/Word (bit) | 16 |
| Maximum Clock Rate (MHz) | 1600 |
| Address Bus Width (bit) | 18 |
| Minimum Operating Supply Voltage (V) | 1.425 |
| Maximum Operating Supply Voltage (V) | 1.575 |
| Mounting | Surface Mount |
