Manufacturer
Cisco
MPN
ONS-SE-G2F-LX
Available
96
Condition
Refurbished
Cisco ONS-SE-G2F-LX - Sfp Ge Lx/fc1-2g Sm Isc-1 Transceiver Module
This SFP (Small Form-Factor Pluggable) module is capable of providing Gigabit Ethernet connectivity over single-mode fiber optic cables, making it ideal for long-distance data transmission. The module supports a data transfer rate of up to 1.25 Gbps and can operate over a distance of up to 10 kilometers. It also supports both Fast Ethernet and Gigabit Ethernet protocols, making it a versatile solution for various network environments.
The Cisco ONS-SE-G2F-LX transceiver module is hot-swappable, allowing for easy installation and replacement without disrupting network operations. It also features digital diagnostics monitoring (DDM) capabilities, which provide real-time monitoring of key parameters such as temperature, voltage, and optical power levels. This transceiver module is compatible with a wide range of Cisco networking equipment, including switches, routers, and optical transport platforms.
Key Technical Data
| Media Type: | Single-Mode Fiber (SMF) |
|---|---|
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 12 dB |
| Maximum Distance: | 10km |
| Supported Data Rate: | 100-2.67Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 100M Ethernet (100Mbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), STM-1 (155Mbps), STM-4 (622Mbps), STM-16 (2.488 Gbps), ODU0 (1.244Gbps), ODU1 (2.498Gbps), OTU1 (2.66Gbps), CPRI option 2 (1228.8 Mbps), CPRI option 3 (2.458 Gbps) |
| DDM/DOM: | Support |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -6 dB |
| Maximum Transmitting Power: | 0 dB |
| Receiver Sensitivity: | -18 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 70-100 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
