TE Connectivity TRA6927M3PB-001 - 4G/3G Multiband Phantom Antenna N-Female
Slide 1 of 1
Manufacturer
TE Connectivity
MPN
TRA6927M3PB-001
Available
205
Condition
New
LAIRD 3G/4G Multi-Band Phantom Antenna for 698-960/1700-2700 MHz Applications. Cross Polarized. Black. 3.3" Radome. N Female connector. TRA6927M3PB-TS1
The TE Connectivity TRA6927M3PB-001 is a high-performance 4G/3G multiband phantom antenna designed for use in various wireless communication applications. This antenna is equipped with an N-Female connector, making it compatible with a wide range of devices.
This antenna operates on multiple frequency bands, including 698-960 MHz and 1710-2700 MHz, providing reliable connectivity in both urban and rural areas. It also features a high gain of up to 3 dBi, ensuring strong and stable signal reception. Its phantom design allows for easy installation and eliminates the need for a ground plane, making it a convenient choice for a wide range of applications.
Mechanically robust for both Indoor/Outdoor applications
Applicable for both 3G and 4G application
WiMAX 2300/2500/2600 bands
Domestic Cellular and Global GSM
Phantom out-performs a 3 dBi whip in many applications
| Frequency Range | 698-806MHz: LTE 806-896MHz: Cellular/iDEN 890-960MHz: GSM Europe 1710-1880MHz: 1700 AWS 1710-1880MHz: DCS Europe 1850-1990MHz: PCS 1900-2170Mhz: UMTS 2110-2155MHz: 1700 AWS 2.4-2.5GHz: WiFi |
| Impedance | 50 Ohms |
| Antenna Gain (Peak) | 698-960MHz: 3.5dBi 1710-1990MHz: 5.5dBi 2100-2700MHz: 4.6dBi |
| Radiation | Omni |
| Polarization | Cross Polarized |
| Ground Plane | Metal Ground Plane Required |
| Radome Height | 3.3" |
| Width | 1.44" |
| Color | Black |
| Mount | N/Female Permanet mount Mounts thru metal surface |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 829MHz, 2.2GHz |
| Frequency Range | 698MHz ~ 960MHz, 1.71GHz ~ 2.7GHz |
| Antenna Type | Whip, Straight |
| Number of Bands | 1 |
| VSWR | 2.5 |
| Gain | 5.5dBi |
| Power - Max | 100 W |
| Termination | N Type Female |
| Mounting Type | Base Mount |
| Height (Max) | 3.300" (83.82mm) |
